FEATURES

700W Water-Based Fazer
4,000 CFM* (cu ft/min.) (113 m3/min*) Output
Compact Light Weight Robust Design
Onboard LCD Touch Control Panel
Optional Aria X2 card
Optional Wireless DMX Transceiver Module
Optional MAGRF Wireless and Wired Remotes
*Approximate

PERFORMANCE

Rated Power: 700W
Max Output: 4,000 CFM* (cu ft/min.) (113 m3/min*)
Ready Time: Initial = 6 Minutes*
Fluid Capacity: 0.345 gallons (1.3 liters)
Fluid Consumption: 0.115 oz/min (3.4 ml/min)
Automatic Priming
Hanging Bracket
OVP "Over Voltage Protection"
Sleep Mode
*approximate


COMPATIBLE FLUID

Atmosity Extreme Filtered Fog Fluid (AEF-2L, AEF-4L and AEF-20L)


CONSTRUCTION

Thermally Protected Heat Exchanger
Sealed Fluid Reservoir
External Visual Fluid Level Detection
Compact Light Weight Mobile Design


CONTROL

4 DMX Channel Modes (1 / 2 / 3 / 5)
Onboard LCD Touch Control Panel
DMX-512 and RDM Protocol Support
Optional Wireless DMX Transceiver Module
Optional MAGRF Wireless and Wired Remotes


CONNECTIONS

Locking 5pin XLR Connector In/Out
IP65 Locking Power Connector In
With Wired Digital Communication Network


SIZE / WEIGHT

Length: 338mm (13.3 in)
Width: 160mm (6.3 in)
Height: 387mm (15.2 in)
Weight: 10.2kg (22.48 lbs)


ELECTRICAL

AC120V 60Hz (US Version)
AC230V 50Hz (EU Version)
9A @ 120VAC(NFB)
5A @ 230VAC - 240VAC
Max Power Consumption: 720W


THERMAL

Maximum Ambient Temperature (Ta max) 104°F (40°C)
Exterior Surface Temperature, Steady State: 122°F (50°C)
